$1,549.00
| Wingspan | 2018 mm (79.4 in) |
|---|---|
| Length | 1800 mm (70.9 in) |
| Flying Weight | 10.7kg (23.5 lb) with 1800cc Aviation kerosene |
| Turbine Engine | SW80B 8KG brushless / SW60B 6KG brushless (required & not included) |
| Cruising speed | 150～200 km/h |
| Flying time | 3～5 mins (full throttle) |
| Wing area | 56.5 dm2 |
| Wing load | 184.1 g/dm2 |
| Main material | 20 times EPO |
| Painting surface | matte paint |
| Suitable experience level | □Zero basis □Beginner □Intermediate ■Advanced |
| PNP Assembly difficulty | □☆10mins ■★☆30mins □★★60mins |
| Suitable for ambient temperature | 0℃～40℃ |
| Radio System | 7 channel (required & not included) |
| Control System | MFC-2085 |
| Servos | 7.4V 25g×2 Metal gear with 480mm lead (left & right ailerons forward) |
| Recommended Battery | 2S,7.4V,5200mAh×2,LiPo with XT60 type plug(required & not included) |
| Ailerons | Yes |
| Flaps | Yes |
| Elevator(Horizontal tail) | Yes |
| Rudder(Vertical tail) | Yes |
| The smoke system | No |
| LED lights system | Yes |
| Electromagnetic brake system | Yes |
| Reinforced gyro | Selective configuration (not included) |
| Packaging / Size | Packing Box + Outer Box(Card mark)/52.56×21.3×16.9(inch) |
| CG (Center of Gravity) | 180mm from the leading edge of the Main Wing |
| Landing Gears | Metal electric retractable hydraulic landing gear×3 |
| Battery Charger | LiPo battery charger (required & not included) |
* Fuselage×1 pcs
* Left main wing×1 pcs
* Right main wing×1 pcs
* Left Horizontal tail ×1 pcs
* Right Horizontal tail×1 pcs
* Vertical tail×1 pcs
* Nose×1 pcs
* Cockpit×1 pcs
* Left auxiliary tank×1 pcs
* Right auxiliary tank×1 pcs
* 1# Main wing carbon tube L=820mm external diameter 16mm×1 pcs
* 2# Main wing carbon tube L=760mm external diameter 10mm×1 pcs
* Horizontal Stabilizer carbon tube L=650mm external diameter 6mm×1 pcs
—–Accessories Bag 1 ×1 pcs
* Screw (HM3×10mm)×8 pcs (Horizontal tail)
* Screw (HA3×10mm)×8 pcs (Vertical tail / Tail nozzle)
* Screw (HA3×14mm)×8 pcs (Engine)
* Screw (HM3×14mm)×8 pcs (Wing)
* Screw (HM4×25mm)×8 pcs (Auxiliary tank)
* Screw (PWM6×70mm)×6 pcs (Nose)
—–Accessories Bag 2 ×1 pcs
* 100mm signal line(JR male+JR male) ×8 pcs
* Manual×1 pcs
* SW80B 8KG brushless / SW60B 6KG brushless (required & not included)
* 7 channel radio system(radio & receiver) (required & not included)
* 2S,7.4V,5200mAh×2,LiPo with XT60 type plug (required & not included)
* LiPo battery charger (required & not included)
